USB Monitor Pro

Overview

USB Monitor Pro is an effective and simple in use analyzer of USB traffic for Windows. It allows monitor incoming and outgoing data of a USB device plugged into the computer.

USB Monitor Pro is a complete software solution, so you don't need any additional expensive hardware.

It's an indispensable tool for a developer of firmware and drivers for USB devices, expanding developer's arsenal.

Simplicity of Use!

USB Monitor Pro development is based on a long-standing experience in USB devices drivers development and you can easily make sure how much it's convenient and simple in use. Just choose the device and start monitoring.

Monitoring of Critical Information when Developing USB Devices Drivers

No critical information will pass by USB Monitor Pro. INTERNAL_IOCTLs, URB packets and IRP packets of PnP and Power Management subsystems will be captured and displayed immediately. The monitoring takes place in both directions (from device driver to the Host Controller Driver and vice versa).

Reports, Nothing Unnecessary

Format of captured data displaying is arranged to simplify data understanding as much as possible.

In spite of chronological ordering of captured information it's possible to get more detailed information (e.g. URB packet structure, hex-dump of packets carrying data) for every URB and INTERNAL_IOCTL packets at any time. Just click on a packet and you'll get it.

Comparison of Packets Before and After Processing by the Host Controller Driver

USB Monitor Pro analyzes captured traffic and allows to immediately find URB request (or INTERNAL_IOCTL) come out to the Host Controller Driver and also corresponding URB packet processed by the Host Controller Driver. You will see both packets at once to compare them and then to make a corresponding conclusions.

Monitoring of a Hot-Plugged Device

When the program works in this mode all you have to do to start monitoring is to plug a USB device into the computer. The program automatically starts monitoring the first plugged USB device.

Searching and Filtering

Built-in search engine allows finding wanted information rapidly. Moreover, filtering mechanism allows dynamic hiding and showing only needed types of captured data causing automatical hiding of unnecessary packets.

Updating List of Packets in Real Time

Unlike other USB monitoring programs which don't allow to examine captured data while monitoring, USB Monitor Pro is totally free from this limitation. You can easily examine all needed information in real time.

Moreover, you can monitor several USB devices simultaneously.

Saving and Exporting of Captured Data for Further Examination

Captured data can be saved to a file and then can be opened by the program for further examination. Moreover, the data can be exported into different formats for further analysis.

Benefits

The real professionals in USB communications have been developing and supporting USB Monitor Pro. The main goal we strive for is to help you to save money, time and probably nerves.

We want you not to waste your time on monotonous "digging" of protocols and data but concentrate your talent on your project working with the pleasure.

Target Groups

USB Monitor Pro is successfully used for software development, devices drivers debugging and analyzing of USB traffic. It's also a powerful tool for effective testing and optimization.

The program is successfully used for tasks like protocols analysis, reverse-engineering of USB protocols and functionality determination of third-party device drivers.

USB Monitor Pro is used by software developers, hardware engineers, IT support specialists, programmers, beta-testers, industrial control personnel, SCADA software engineers, science technicians, systems integrators, consultants, lab experts, university students.

Features

Compatibility
32-bit: Windows Vista, XP, 2000, Server 2003, Server 2008, Server 2008 R2, Windows 7 64-bit: Windows Vista, XP, Server 2003, Server 2008, Server 2008 R2, Windows 7
USB 1.x and 2.0
Monitoring Information
Monitoring of data between USB device driver and the Host Controller Driver
Monitoring of all types of USB Request Block (URB)
Monitoring of all IOCTL_INTERNAL_USB_*
Monitoring of IRPs of PnP and Power Management subsystems
Monitoring Features
Updating list of packets in real time for non-stop analysis
Monitoring of a hot-plugged device
Saving of captured data for further examination
Exporting captured data to different formats for further analysis
Separate records for request initiation and completion
Filtering mechanism for limiting the volume of captured data to concentrate on the most important information
Monitoring of several USB devices simultaneously
Software restart of USB device
Obtaining complete USB device information (device descriptor, configurations, interfaces, endpoints)
User Interface
Real-time displaying of time stamped events
Displaying of detailed information about URB and INTERNAL_IOCTL
Powerful data searching
Showing filters for hiding/unhiding certain types of captured packets
Easy switching between packet come into the Host Controller Driver and corresponding packet come out from the Host Controller Driver
